Growatt SPI 3000-22000

Short Description:

Place of Origin:Shenzhen, China

Brand Name:GROWATT

Model Number:SPI 3000-22000

Input Voltage:900V

Output Voltage:500V-680V

Output Current:8A-45A

Output Frequency:0-50/60Hz

Output Type:Single, DUAL

Size:475*325*155mm

Type:DC/AC Inverters


Product Detail

Product Tags

Quick Details

Place of Origin:Shenzhen, China
Brand Name:GROWATT
Model Number:SPI 3000-22000
Input Voltage:900V
Output Voltage:500V-680V
Output Current:8A-45A
Output Frequency:0-50/60Hz
Output Type:Single, DUAL
Size:475*325*155mm
Type:DC/AC Inverters
Inverter Efficiency:98.70%
Certificate:CE,TUV

Warranty:5 Years
Weight:14kg-22kg
Topology:Transformerless
Protection Level:IP65
Cooling:Smart Air Cooling
Self-Consumption:<1W
Operating Temperature:-25~60℃
Product name:Solar Inverter
Application:Commercial Rooftop Inverter
Communications:WiFi/GPRS/4G
Short circuit protection:Yes
OEM:Yes

Products Description

GS3000
GS3001
GS3002

Solar Pump System Diagram

捕获

Technical Parameters

Datasheet

SPI 3000

SPI 4000

SPI 5500

SPI 7500

SPI 9200

SPI 11000

SPI 13000

 SPI 15000

SPI 18500

SPI 22000

Rated Output Power (W)

3000W

4000W

5500W

7500W

9200W

11000W

13000W

15000W

18500W

22000W

Max. Output Current (A)

8A

10A

 13A

18A

21A

23A

28A

30A

38A

45A

Output Frequency (Hz)

0-50/60Hz

MPPT Efficiency

3PH 380V

Qty. of PV Input Ports

2

3

6

Recommend PV power

3600W

4800W

6600W

9000W

11000W

13200W

15600W

18000W

22200W

26500W

Recommend pump capacity

2.2KW(3HP)

3KW(4HP)

3.7KW(5HP)

5.5KW(7.5HP)

7.5KW(10HP)

9.2KW(12.5HP)

11KW(15HP)

13KW(17.5HP)

15KW(20HP)

18.5KW(25HP)

Max. DC Input Voltage (Vdc)

900V

Recommed MPP Votage (Vdc)

500-680V

Ingress Protection

 IP65

Weight (kg)

14kg

15kg

16kg

22kg

Demension (mm)

478/325 /155

563/346/148

533/405/190

Why Choose Us

1. ALife Solar provides solar panels, inverters, solar systems, solar street light systems, solar water pump systems, etc.Can provide our customers with one-stop solutions.

2. The products have certifications such as ISO9001, TUV, JET, CQCand CE.

3. Along with a 12 years manufacturer warranty (25 or 30 years linear performance guarantee) for solar panels and 5-year manufacturer warranty for solar inverters, which are all widely used in more than 60 countries and regions.

4. We possess a contracting qualification for mechanical and electrical equipment installation. Equipped to undertake Engineering, Procurement and Construction (EPC) projects for photovoltaic power generation system, providing with:
1). Project consultation
2). Site survey
3). System design
4). Scheme development
5). Production and transportation
6). Construction and installation
7). Grid connection management
8). Power station operation and maintenance services
With over 800+ MW of project expertise, ALife Solar provides an efficient, safe and durable photo-voltaic power generation system with customer satisfaction globally and is willing to work with you to illuminate life with sunshine and create a greener, healthier and better future!

Packaging & Delivery

Supply Ability: 10000 Set/Sets per Week
Packaging Details: carton and pallet,standard international package
Port: Shanghai/Ningbo Port

Lead Time:

Quantity(Pieces) 1 - 10 >10
Est. Time(days) 15 To be negotiated
